Alchemist Product8 Integrated Amplifier
Orange line
Alchemist Product Eight Integrated Amplifier
Orange line

Specifications | Images | Downloads | Design | Servicing | 2nd Hand Market

Orange line

S    P    E    C    I    F    I    C    A    T    I    O    N    S

Orange line
Output @ 1kHz into 8 ohms:   100 Watts (Class A/B)
Input Sensitivity:   390mV
Frequency Response @ 3V:   -3dB @ 50KHz
Residual Noise (Max vol):   <2mV
Total Harmonic Distortion:   <0.5% THD
Power Consumption (Nominal):   100 Watts
Power Consumption (Peak):   370 Watts
External Fuse Rating:   8A@110-120V
4A@220-240V
Dimensions (W x H x D):   470mm x 360mm x 105mm
Weight (Packed):   20Kg
Orange line
Orange line
Downloads:
Instructions (820KB)
Orange line
Design:
Orange line
Servicing:
DO NOT ATTEMPT ANY WORK YOURSELF UNLESS YOU ARE COMFORTABLE WITH ELECTRONICS AND KNOW WHAT YOU ARE DOING
Orange line
2nd Hand Market:
Orange line
Have you something to contribute to this page? Please contact the site administrator.
